In Stock External UBEC With Power Supply Filter Adaptor Board Built-in 5V UBEC for MTSKR1905WF & MTSKR2005WF Receiver

The  outlook, size and wire color may vary for different production batch, Please refer to the actual product you receive.

Application: Work with Maytech MTSKR1905WF, MTSKR2005WF Remote; Work with VESC/ ESCs for electric skateboard, elongboard, efoil, foil assist board, etc.,

Features:

• Filters main battery voltage signals to eliminate interference for receiver PCB.
• Delays filtered voltage signal transmission to receiver by 7 seconds after power-on, preventing initial voltage fluctuations.
• Integrates 5V DC-DC converter to directly step down main battery voltage for receiver power supply, by passing unstable ESC BEC circuits. (UBEC function: Get power from the main battery, convert the voltage from 9-75V to 5V for receiver.)
• Maintains receiver power for 1 second after shutdown via built-in energy storage circuit, protecting I/O ports from voltage spikes.
• Provides anti-interference and overvoltage protection for receiver-output PWM and UART signals.
• To protect the receiver from spark interference.
• Built-in 9-75V convert to 5V DC-DC Module, even if your ESC is without BEC built in, this module can draw power from main battery to power for receiver.
• Compatible with Maytech MTSKR1905WF & MTSKR2005WF remote control, can display main battery power on remote, no need to lead wire from main battery side manually.
• MTSRR1905WF receiver can be directly plugged to this module, save space.
• Compatible with ESC/VESC, work with ESCs that with or without BEC.
