Inv/Chgr, Freedom XC, 2000W 12V 230V

Description

The Freedom XC inverter/charger offers premium performance in a lightweight compact package. It cranks out full output in invert or charge mode from -20 to 40 Degree C for operation in all climate temperatures. The extended surge rating of the Freedom XC makes it ideal to start difficult loads including a fridge and microwave. The quick connect terminals at AC in/out make installation a breeze.

Xantrex 817208012 Attributes

• Output Voltage: 240 Volt AC
• Input Voltage: 12 Volt DC
• Continuous Output Power (W): 2000 Watt
• Peak Output Power (W): 4000 Watt
• Ampere Rating: 16.7 Amp
• Efficiency: 91 Percent
• Length (IN): 15.4 Inch
• Width (IN): 10.8 Inch
• Height (IN): 4 Inch
• Remote On/Off Capable: Yes
• With USB Port: No
• With Volt/Watt Meter: No
• With Short Circuit: No
• With Reverse Battery Protection: No
• With Thermal Protection: No
• With Battery Cables: No
• With Built-In Charger: Yes
• With Fuse: No

Xantrex 817208012 Features & Benefits

• A True Sine Wave Inverter With A Built-In Lithium-Ion Battery Charger And Transfer Switch In A Compact, Lightweight Footprint
• Configure And Monitor System Performance Via Bluetooth App Available On The Optional Bluetooth Remote Panel
• Extended Surge Rating: Surges To 2X Continuous Power For At Least 2 Seconds For Motor Loads
• True Sine Wave AC Power: For Operation Of Sensitive And Motor Loads
• Ignition Control: Feature To Turn Inverter On/Off Via A 12 VDC Signal And To Minimize Battery Drain By Switching The Inverter Off When The Ignition Key Is Turned Off
• Wide 10 To 17 VDC Input Range: Ensures Inverter Operation On High Voltage Alternators Found On Many New Vehicle Chassis
• Programmable AC Under Voltage (170 To 220 Volt) Shutdown: Feature Ideal To Operate Under Weak Shore Power Or Generator Input
• Built In 30 Ampere AC Transfer Relay: Senses When Outside AC Power Is Present And Transfers The Load From The Inverter To The Source Of Incoming Power
• Limited 2 Year Warranty

Xantrex 817208012 Installation Instructions

• Freedom-XC-Inverter-Charger-230V-Owners-Guide-975-0821-01-01_Rev-C_ENG.pdf

Xantrex 817208012 Warranties

• Freedom_XC_Warranty-Terms-n-Conditions_NA-3.pdf

Xantrex 817208012 Technical Bulletins

• 20200724_FREEDOMXC2000_230V_Datasheet.pdf

Freedom X Inverter/Charger, MFG# 817-2080-12, 2000 watt-230V-50Hz AC true sinewave output, 2X surge output, 12VDC input, 80 Amp charger, ignition control, 30A transfer relay, optional GFCI outlet, optional remote control. 15.4″ x 10.8″ x 4.0″, 16.3 lb.

XANTREX Inv/Chgr, Freedom XC, 2000W 12V 230V are brand new. XANTREX Inv/Chgr, Freedom XC, 2000W 12V 230V Freedom X inverter/charger, MFG#817-2080-12, 2000 watt-230V-50Hz AC true sine wave output, 2X surge output, 12VDC input, 80 Amp Charger, ignition control, 30A conversion relay, optional GFCI socket, optional remote control. 15.4 inches x 10.8 inches x 4.0 inches, 16.3 pounds!!!!—-
