Lopolight Combined Sidelight 1nm Half Circle Housing #100-004

Description

Lopolight 100-004 Sidelights

Combined SideLights – 1nm f/Vessels up to 39′(12M) – Half Circle Housing – Horizontal Mounting

Features:

• LED (Light Emitting Diode) navigation light
• Unique and precise definition of light angles
• Rugged and unbreakable: Precision machined anodised aluminium housing protects the LED’s and electronics
• Completely waterproof and vibrationproof: Interior is fully filled and sealed with special potting resin
• Waterproof to IP 68+ (submersible)
• Lifetime over 50,000 hours or 4,200 nights
• Low power consumption – 70 to 90% less than traditional navigation lights
• Full brightness with input voltages ranging from 10 to 32 Volts
• All Lopolights have been tested several times during production, a total of more than 24 hours
• Easy to install, adaptor and screws included (when applicable)

Specifications:

• USCG Approved
• Light Measurements: 3.64″(92.5mm) x 2.95″(75mm) x 1.14″(29mm)
• Weight: 8.2oz(230g)
• Materials: Anodised Aluminum 25µ, PMMA lens, A4 Stainless Steel screws, Epoxy, Polyurethane
• Supply Voltage: 10-32VDC
• Power Consumption: 1.4W
• Current @ 12VDC: 0.12A
• Current @ 24VDC: 0.06A
• Intensity: >1.2cd
• Visibility (@K+0.8): 1nm
• Number of LEDs: 36

  Included in Package:

  • (1) Navigation light, pre-cabled with 2.5M shielded marine gradecable
  • (2) Mounting Screws (M6*8mm)
  • Installation Guide

  Specifications:

  Housing = NONE
  Lens Color = Red/Green
  Visibility Arc (Degree) = NONE
  Visible Range (Miles) = 1nm

  Normalized SKU: 100004
