Description
ACHIEVED EN250 WORK OF BREATHING REQUIREMENTS AT THE DEPTH OF 200 M AT A BREATHING RATE OF 62,5 L/MIN WHILE USING A BREATHING MIX OF 6,7% OXYGEN, 83,3% HELIUM AND 10% NITROGEN. THIS GAS MIXTURE HAS A DENSITY AT 200M EQUIVALENT TO THE DENSITY OF AIR AT 50M
1ST STAGE
- PVD COATING
- SWIVEL TURRET
- NATURAL DFC ON ALL LP PORTS
- TILTED HP PORTS
- AST – 1ST STAGE DRY SYSTEM
- COMPACT DIMENSIONS
2ND STAGE
- METAL 2ND STAGE WITH PVD COATING
- TWIN POWER SYSTEM
- ADJUSTABLE BREATHING COMFORT
- P.A.D. – PNEUMATICALLY ASSISTED DESIGN
- HIGH AIR FLOW
- WIDE PIVOTING PURGE BUTTON
- COLD WATER USE
- SUPERFLEX HOSE
- ACHIEVED EN250 WORK OF BREATHING REQUIREMENTS AT THE DEPTH OF 200 M AT A BREATHING RATE OF 62,5 L/MIN WHILE USING A BREATHING MIX OF 6,7% OXYGEN, 83,3% HELIUM AND 10% NITROGEN. THIS GAS MIXTURE HAS A DENSITY AT 200M EQUIVALENT TO THE DENSITY OF AIR AT 50M
| Material: | Metal Technology |
| First stage: | Balanced Diaphragm |
| Lightweight yoke: | Yes |
| High pressure ports: | 2 HP 7/16″ UNF ports |
| Low pressure ports: | 5 LP 3/8″ UNF ports |
TECHNICAL SPECIFICATIONS
| INT | DIN | NX | |
| First Stage Weight: | 964g | 790g | |
| Second stage weight (g): | 329g | 329g | 329g |
| Total Weight (including hose): | 1429g | 1255g |
