Description
Navico SonarHub Sounder Module
The compact SonarHub sounder module provides an all-in-one solution for adding best-in-class StructureScan HD and CHIRP sonar capabilities to compatible Lowrance HDS and Simrad NS series multifunction displays.
An easy-to-install, plug-and-play, all-in-one network solution – the SonarHub Sounder Module makes it easier than ever to identify productive fishing areas with connectivity to the latest sonar technologies for Lowrance HDS and Simrad NS displays – including CHIRP and StructureScan HD imaging – as well as the Lowrance SpotlightScan bow-mounted solution for HDS Gen2 models.
Features
- Compact, all-in-one sonar module delivers StructureScan HD and CHIRP sonar technologies.
- CHIRP sonar with Airmar TM150M or B150M transducers delivers extremely efficient pulse generation that provides improved target resolution and noise rejection, as well as wide coverage for perfect arches that clearly identify fish targets.
- StructureScan HD offers best-in-class, side-scanning range and resolution, plus DownScan Imaging to provide crystal-clear, picture-like views of what’s beneath your boat.
- Optional transducers include Airmar TM150M and B150M single-channel CHIRP transducers, existing StructureScan HD transducers, and the SpotlightScan surround-scanning sonar transducer.*
- Plug-and-play compatibility with Lowrance HDS Gen1 (not including SpotlightScan and CHIRP sonar), HDS Gen2 and Gen2 Touch fishfinder/chartplotter models, and Simrad NSO,NSE and NSS series multifunction displays.
- Three built-in Ethernet ports allow for quick and convenient networking without the need for an extra Ethernet networking module.
- Supported by Lowrance Advantage Service and Simrad Advantage Service programs.
*SonarHub Sonar Module not required for SpotlightScan functionality with HDS Gen2 Touch displays.
Sonar imaging is unprecedented, all in one box! The underwater beauty is unparalleled! Lowrance’s compact all-in-one waterproof SonarHub module and compatible Lowrance combined chartplotter/fishfinder system provide StructureScan HD and CHIRP Sonar functions. Lowrance SonarHub can clearly identify fish and seabed structures, and enhance target separation through CHIRP (Compressed High Intensity Radar Pulse), and receive photos of the image below through DownScan, and obtain the best-in-class side scan range and resolution through StructureScan HD. Lowrance SonarHub is an ideal plug-and-play type for installing HDS Gen2 and Gen2 Touch combination units (excluding SpotlightScan and CHIRP sonar) on HDS. SonarHub is even a SpotlightScan sensor compatible with the HDS Gen2/Gen2 Touch unit, which can view the scene in front of and around the spacecraft and identify hot spots before launching. The built-in three Ethernet ports provide easy-to-use networking options without the need to add other networking modules. SonarHub module has 500W RMS (StructureScan) and 250W RMS (CHIRP) transmission power, which is ideal for extending the current Lowrance HDS settings. A sensor is required and sold separately. !!!!—-
PRODUCT ID: 50453
SKU: NVN-50453
CSKU: CWR-50453
REWRITE: 61564-navico-sonarhub-153-sounder-module
MPN: 000-11142-001
UPC: 9420024124734
ASIN:
WSKU: LOW00011142001
SSKU: LOW-000-11142-001
KSKU: LOW0011142001
GSKU:
MSKU:
LSKU: 941-00011142001
NAME: Navico SonarHub Sounder Module
NAME_EX: NAVICO SONARHUB SOUNDER MODULE ONLY NO DUCERS
PTITLE: Navico SonarHub Sounder Module
TYPE: Marine Navigation & Instruments | Network Cables & Modules
VENDOR: Navico
Google Category: ELECTRONICS > MARINE ELECTRONICS > MARINE CHARTPLOTTERS & GPS
Amazon Category:
Amazon Title:
Google Title: Lowrance SonarHub Sounder Module
Amazon Category:
Gtags:
| Lowrance |
GSpecs:
