Poly-Planar 4CH, 120W, Audio Amplifier w/Volume Control

Description

4 Channel,120watt, Audio Amplifier with volume control
Part Number: ME60

The ME60 is a four channel 120 Watts RMS audio amplifier of delivering up to 30W RMS per channel. It has a compact, water resistant design that allows for flexible mounting possibilities, and makes it simple to expand the audio system capabilities for any installation.

Uses:

• To add additional loudspeakers to a current audio system
• To provide amplification for a separate audio zone
• As a stand-alone system amplifier for any audio source
• To power standard speakers or speakers and subwoofer

Features

• Powers up to (8) 4ohm speakers
• Internal distortion limiting circuits
• Dedicated gain level control
• External volume control with ON/OFF switch included
• Water resistant design for marine use
• Rear channels switchable from full range to powered sub out.

Specifications

• Speaker Impedance:2-8 ohm
• Output Power (4 ohm load) 20 Watts RMS per Channel (50W Peak):(2 ohm load) 30 Watts RMS per Channel (70W Peak)
• Frequency Response:20Hz-40kHz
• Low Pass Crossover:18 – 245 Hz
• Operating Voltage:13.8V DC (10V-16V)
• Maximum Current Draw (full power):8-10amps
• Dimensions (approx. w x h x d):175mm x 115mm x 35mm 6.9″ x 4.5″ x 1.4″
• Installation Clearance:250mm free space top/sides
• Weight:1.65lbs
• Volume Control Cable Length:290cm/114″

  It has a compact waterproof design that enables flexible installation possibilities and makes it easy to expand the audio system functions for any installation. to …!!!!—-
