Raymarine Axiom+ 12 RV – 12″ Chartplotter/Fishfinder w/RV-100 T/M Transducer & Navionics+ Chart

Description

The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality.

Raymarine 7063903NAG Attributes

• Maps: Navionics+ USA And Coastal Canada Charts
• Display Size: 12 Inch
• Display Type: WXGA 1280 x 800 Pixels Resolution
• Interface: Touchscreen Interface
• Dimensions: 12.36 Inch Width X 3 Inch Depth X 8.54 Inch Height
• Waterproof: IPX6/ IPX7 Waterproof
• Sonar Compatibility: Chirp Sonar

Raymarine 7063903NAG Features & Benefits

• High Frequency CHIRP Sonar For Targeting Fish And Determining Bottom Density
• CHIRP DownVision Sonar For High Definition Views Of Structure, Fish Habitat And Man-Made Objects
• CHIRP SideVision For Scanning Beyond Casting Distance To See Fish, Structure And Submerged Objects Out To The Sides Of The Boat
• RealVision 3D Sonar Which Provides A Gyro-Stabilized, GPS-Locked Bathymetric Model Of The Bottom And Water Column
• Upgraded IPS Display Technology Delivers Charts, Sonar, Radar And Video In Stunning Color And Improved Viewing With New LightHouse Color Themes, Including Day, Dusk And Night Mode
• Smart And Intuitive LightHouse OS Makes Navigating Easy
• Axiom+ Features HydroTough Nano-Coated, Impact-Resistant Screens That Dispels Water, Oil And Smudges
• All-Weather HydroTough Technology Delivers Improved Color And Contrast And Accurate Touch Controls – Even When Wet
• Features Navionics+ USA And Coastal Canada Chart And RV-100 Transducer
• Limited 2 Year Warranty

Raymarine 7063903NAG Installation Instructions

• Axiom MFD Installation instructions 87298-3-EN.pdf
• Axiom MFD Front Installation Kit Installation instructions 87304-1-EN.pdf
• Axiom MFD Installation instructions 87414 (Rev 2) (EN).pdf

Raymarine 7063903NAG Warranties

• Raymarine-Global-Limited-Warranty-01-Jul-17-rev1-0.pdf

Raymarine 7063903NAG Technical Bulletins

• Axiom MFD Installation instructions 87414 (Rev 2) (EN).pdf
• Axiom MFD Front Installation Kit Installation instructions 87304-1-EN.pdf
• Axiom MFD Installation instructions 87298-3-EN.pdf

Axiom+ 12 RV – 12″ Chartplotter/Fishfinder with RV-100 Transom Mount & Navionics+ Chart

The performance-tuned Axiom® Plus is a generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar. Higher resolution IPS displays deliver 25 percent more brightness and day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.

PERFORMANCE TUNED

• Designed for speed, responsiveness, and future expansion
• Powerful quad-core processor, plus increased onboard storage for personal data and apps
• Fluid and fast chart redraw of Raymarine LightHouse Charts, plus Navionics and C-MAP
• ClearCruise™ Augmented Reality-capable for smarter navigation decisions
• Smart and intuitive LightHouse 3 OS makes navigating easy

MAXIMUM VISIBILITY

• Upgraded IPS display technology delivers charts, sonar, radar, and video in stunning color
• IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays
• 7-, 9-, and 12-inch all-weather displays are 25 percent brighter (up to 1,800 nits)
• HydroTough™ Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls
• Improved viewing with LightHouse 3 color themes, including light, dark, and night mode

The Axiom+ 12 RV includes surface and trunnion mounting kits, mounting hardware, power/data cable, and installation instructions.

Features:

• IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays
• LightHouse 3 OS is fast, fluid, and easy to learn. An uncluttered interface that is easily personalized for your style of navigating
• RealVision 3D™ Sonar Built-In – Go fishing like never before with life-like 3D imagery of structures and fish – an unprecedented view of the underwater world
• Powerful 4 Channel Sonar supports RealVision 3D, CHIRP DownVision, SideVision, High Frequency CHIRP, and 600 Watt (50/200 kHz) sonar
• Wide Spectrum CHIRP sonar transmits on 60 different frequencies for the most life-like sonar imagery and simply the best fish targeting
• Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning
• Support for the best charts from Navionics and LightHouse Raster and Vector Charts sourced from leading map makers like NV Digital, Blue =Latitude, and more
• Navigate Safely at Night with the optional FLIR M100 and M200 compact marine thermal cameras
• Quantum CHIRP Radar Ready – Superior solid state CHIRP radar delivers no compromise performance on long and extremely short range
• Marine Audio Control – Turn up the volume and control NMEA2000 compatible marine audio systems like Rockford Fosgate
• Ready to Network with Raynet Ethernet and NMEA2000. Connect multiple Axiom displays or expand with Quantum, HD radar, IP cameras, engine gauges, autopilots, instruments, and more
• Built-in Wi-Fi lets you to stream and control Axiom right from your smartphone or tablet. You can also sync Axiom’s waypoints, routes, and charts with Navionics mobile app

RV-100 – RealVision 3D™ All-In-One Transom Mount Transducer

Raymarine’s RV-100 All-In-One Transom Mount Transducer lets you easily identify structures and locate fish with the life-like clarity of RealVision 3D sonar. The RV-100 is a 4-channel, Wide Spectrum CHIRP transducer with DownVision™, SideVision™, high frequency CHIRP fish targeting and RealVision 3D™ sonar inside. The transducer has a built-in attitude and heading reference system (AHRS) that stabilizes the sonar imagery, automatically compensating for vessel motion. You’ll enjoy crystal-clear imagery in waves, swells and while maneuvering. The RV-100 also has a built-in fast response water temperature sensor for quick, accurate readings.The RV-100 is designed for easy transom mounting on outboard-powered motor boats. It features a rugged, marine-grade stainless steel mounting bracket with integrated kick-up to prevent damage in the event of a strike with floating debris, rocks, or stumps.The RV-100 can also be removed from the transom bracket and attached to the stainless Jack-Plate mounting bracket (sold separately) which is ideal for bass boats, flats boats and skiffs. The RV-100 can also be mounted onto stepped hull vessels using the optional stainless steel step-mounting bracket (sold separately)

What’s in the Box?

• RV-100 All-In-One Transom Mount Transducer with 8-meter (26-foot) cable
• Transom bracket
• Mounting hardware
• Installation instructions

Raymarine Axiom+ 12 12″ Muilti-Function Display with RealVison Sonar, With RV100 Transducer with Navionics North America Nav+ Charts

Model: E70639-03-NAG

• Fluid and fast chart redraw of LightHouse, Navionics, and C-MAP electronic charts.
• Powerful quad-core processor, plus increased onboard storage for personal data and apps.
• Smart and intuitive LightHouse 3 OS makes navigating easy.
• ClearCruise™ Augmented Reality-capable for smarter navigation decisions.
• Nano-coated, impact-resistant glass screen repels water, oil, and smudges for better viewing and accurate touch controls.
• IPS display technology delivers wider viewing angles and sharp contrast at twice the resolution of traditional displays.
• Network with multiple Axiom displays, radars, sonar, and more.
• Next-generation, high-performance 10 Hz GPS/GNSS receiver with 4X increased sensitivity for accurate positioning.

The performance-tuned Axiom Plus is a new generation of award-winning Raymarine multifunction displays. Optimized for speed, Axiom Plus is equipped with a powerful quad-core processor for industry-leading responsiveness and speed, giving you the power to seamlessly redraw charts, navigate with augmented reality, and experience RealVision™ 3D sonar.

New, higher resolution IPS displays deliver 25 percent more brightness and new day/night color palettes offer enhanced visibility in any lighting condition. Axiom Plus features the renowned LightHouse 3 OS, the most powerful and easy-to-use Raymarine MFD operating system to date.

Specifications

What’s in the Box:

• Multifunction Display
• Trunnion bracket
• Trunnion knobs x 2
• Suncover — Trunnion mount
• Panel mount gasket for surface/flush mounting
• M5x58 Threaded studs x 4
• M5 Thumb nuts x 4
• Documentation pack
• DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in)
• Power/NMEA 2000 cable (with 1.5 m (4.92 ft) power lead and 0.5 m (1.64 ft) NMEA 2000 lead)
• Rear mounting brackets
• Navionics North America Nav+ Charts mSD
• RV100 Transducer

Raymarine Axiom + 12 12-inch multifunction display with RealVision sonar, with RV100 sensor and Navionics North America Nav + chart model: E70639-03-NAG, smooth, fast…!!!!—-
