Raymarine Axiom™ Pro 12 S MFD w/Single Channel High CHIRP Sonar – Navionics+ North America Chart

Description

The Axiom Pro S line of networked chartplotter displays offers premium all-in-one performance with blazing fast quad-core processing and the simplicity of the LightHouse operating system. Optically bonded IPS displays bring charts, radar and navigation data to life in all lighting conditions, while Raymarine HybridTouch ™ offers the ease of touch screen and the confidence of keypad control when seas are rough. Built-in high CHIRP sonar provides reliable depth and bottom imaging for worry-free cruising. Expand Axiom Pro S into a multifunction powerhouse with additional Axiom displays, Evolution autopilot, solid state radar and FLIR thermal night vision cameras.

Raymarine 7048200NAG Attributes

• Maps: Navionics+ USA And Coastal Canada Charts
• Display Size: 12 Inch
• Display Type: WXGA 1280 x 800 Pixels Resolution
• Interface: Touchscreen Interface
• Waterproof: IPX6/ IPX7 Waterproof
• Sonar Compatibility: Built-In CHIRP

Raymarine 7048200NAG Features & Benefits

• Powerful Chartplotting: Navigate, Pan And Zoom Effortlessly Through LightHouse, Navionics Or C-MAP Charts With Axiom Pro’s Fast Quad-Core Processor
• Trusted By The Pros: Axiom Pro Displays Incorporate The Same Chartplotting, AIS And Radar Technologies Trusted By The United States Coast Guard
• Advanced Radar Navigation: Axiom Pro Is Compatible With Raymarine’s Cyclone And Quantum Solid-State Radars For All-Weather Collision Avoidance And Radar/Chart Overlay
• Cruise And Sail Smarter: With Dynamic Laylines Overlays, Polar Performance Data And Graphical Sailing Dashboard Displays
• ClearCruise Augmented Reality: Upgrade To ClearCruise AR And Make Smarter Navigation Decisions With AIS Targets And Chart Objects Overlaid On High-Definition Video
• Easy To Expand: Standard NMEA0183 And NMEA2000 Ports And Two RayNet Ethernet Ports For Additional Displays, Radars, FLIR And Video Monitoring Cameras
• Intuitive Control
• Features Navionics+ USA And Coastal Canada Chart
• Limited 2 Year Warranty

Raymarine 7048200NAG Installation Instructions

• Axiom Pro MFD Installation instructions 87319-3-EN.pdf

Raymarine 7048200NAG Warranties

• Raymarine-Global-Limited-Warranty-01-Jul-17-rev1-0.pdf

Raymarine 7048200NAG Technical Bulletins

• Axiom Pro MFD Installation instructions 87319-3-EN.pdf
• AxiomPro-Brochure-EMEA.pdf
• AxiomPro-Brochure-EMEA.pdf

Axiom Pro 12 S MFD w/Single Channel High CHIRP Sonar – Navionics+ North America Chart

With single channel high CHIRP Sonarand Raymarine HybridTouch control, Axiom Pro 12 is the new standard for “all-in-one” display. And with a blazing fast quad core processor, a super bright IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience.

Axiom Pro is engineered for captains that want it all. The new standard for “all in-one” multifunction devices. And with a blazing fast quad core processor, a super bright high-definition IPS display, and the smart LightHouse OS, Axiom Pro delivers a fluid and intuitive navigation experience. Axiom Pro is easy to expand into an advanced navigation network that includes multiple Raymarine Axiom displays, CHIRP radar, Evolution autopilot, FLIR thermal night vision technology, and more.

Blazing Fast
Quad core processor delivers instantaneous response and the ability to run multiple apps simultaneously without any slowdowns.
Bold & Bright
Optical bonding technology and IPS display panels give you stunning Color, clarity, and contrast in all lighting conditions. Axiom Pro looks great even through polarized sunglasses.
HybridTouch™
Control Axiom Pro from its multi-touch screen, its buttons and rotary knob, or any combination of both. This choice is yours.
Custom Key
Get instant access to your favorite function with user-programmable Custom Key.
Lighthouse 3 OS
Fast, fluid and easy to learn. The Lighthouse 3 interface is uncluttered and easy to personalize for your style of boating.

Specifications:

• Screen Size: 12.1″
• Display Resolution: 1280 x 800
• Screen Type: Super bright IPS display with optical bonding. Multitouch support
• Mounting Options: Front and trunnion mount Front
• Waterproofing: IPX6 / IPX7
• Memory: 16GB Internal / x2 microSDXC slots
• USB: 1 x USB microAB (rear – charging, external storage device or RCR-SD/USB Accessory (A80440)
• Voltage: 12 / 24 V dc
• Weight: 4.5lbs / 2.04kg
• Operating Temperature: -25ºC to +55ºC (13ºF to 131ºF)
• Wi-Fi
• Ethernet: 2 x 10/100 Mbits/ Network (RayNet)
• NMEA 0183: x2 NMEA 0183 input and x1 NMEA 0183 output (part of power cable)
• NMEA2000: 1 x NMEA2000 port (DeviceNet microC)
• Radar Compatible
• Thermal Night Vision Compatible
• Video Cameras: 1 x Analogue input (BNC). Up to 10 IP Cameras
• Built-in Sonar: High CHIRP Sonar built in – S models only
• External Sonar Compatible
• GPS: Built-in GNSS Receiver: GPS/GLONASS/Beidou – 10Hz 167 Channel | External Accessory: GA150 (A80288)
• Optional Remote Controls
• AIS
• Audio Integration
• Autopilot Control: Evolution Autopilot Control
• Digital Switching: Empirbus compatible
• Dimensions (w x h x d): 14.1″ x 9.17″ x 2.56″ / 358 x 223 x 65 mm

The Axiom Pro 12 S includes surface and trunnion mounting kits and hardware, suncover, power/video/NMEA0183 cable, micro-C DeviceNet (F) to STNG (F) 1M cable, Raynet (F) to Raynet (F) 2M cable and installation instructions. Navionics+ Chart
