VETUS Bow Thruster Panel w/Joystick & Time Lapse

Description

Bow Thruster Panel w/Joystick & Time Lapse

Single joystick panel for operating a Vetus bow or stern thruster. Supplied with quick connectors for BP29 series wiring harnesses. Capable of daisy chaining additional controls for multiple stations.

Features:

• Protected against accidental or unauthorized operation
• Panel power on indicator
• Control circuit overload protection
• Built-in time lapse device when reversing the direction of rotation
• Automatic switch off after 30 minutes inactivity. This feature is user selectable during installation
• In the event of continuous running for more than 2 minutes there is a warning LED and buzzer and the thruster will switch off automatically. The panel will reset itself after 5 seconds.
• Watertight to IP 66
• Dimensions: 85mm x 85mm

This product may not be returned to the original point of purchase.Please contact the manufacturer directly with any issues or concerns.
Quick Guide (pdf)
